Samsung CLX-6260FD Service Manual page 114

4. Alignment and Troubleshooting
Depth 1
c) Information
•
General
This menu displays the machine's serial number, assigned IP address.
•
Software Version
This menu displays all the version of the software installed in the system in detail.
•
Report
You can print the various report that is stored in system.
d) Machine Test
•
Copier
-
NVM Read/Write : This menu changes a configuration value for engine firmware.
Depth 1
105-0030
105-0031
106-0000
106-0010
106-0020
106-0030
106-0121
106-0122
106-0123
-
Test Routines : This menu performs test routines for the engine.
Depth 1
100-0020
100-0030
100-0040
100-0050
100-0120
100-0131
4-32
Depth 2
Depth 2
MHV DC Black
MHV DC Color
Deve DC Yellow
Deve DC Magenta
Deve DC Cyan
Deve DC Black
Yellow Blade DC
Magenta Blade DC
Cyan Blade DC
Depth 2
Black OPC/DEV Motor
Black OPC/DEV Motor
Ready
Color OPC Motor
Color OPC Motor Ready
Exit Motor Forward Fast
Exit Motor Backward
Depth 3
Counter Reset
Engine Footer
Depth 1
106-0124
107-0030
107-0080
109-0010
110-0040
110-0050
110-0060
110-0070
100-0260
100-0340
100-0360
101-0000
101-0010
101-0020
101-0050
101-0070
Copyright© 1995-2012 SAMSUNG. All rights reserved.
Depth 4
Fuser
Pickup Roller
Retard Roller
Torque Limiter
Transfer Roller
Scan
Off
On
Depth 2
Black Blade DC
Transfer1 High Voltage(THV)
Black
Transfer2 High
Voltage(THV2)
Run Temperature offset
LD Power Yellow
LD Power Magenta
LD Power Cyan
LD Power Black
SMPS Fan Run
Feed Motor
ITB Tension Release Motor
Bypass Feed Clutch
T1 Pick-Up Clutch
T2 Pick-Up Clutch
Registration Clutch
Duplex Gate Clutch
