4. Alignment and Troubleshooting

4.1. Alignment and Adjustments

This chapter describes the main functions for service, such as the product maintenance method, the test output related to
maintenance and repair, Jam removing method, and so on. It includes the contents of user guide.

4.1.1. Control panel

NOTE
• This control panel may differ from your machine depending on its model. There are various types of control panels.
• Some features and optional goods may not be available depending on model or country.
• Some buttons may not work depending on the mode (copy, fax, or scan).
Type A (CLX-6260ND/ CLX-6260FD / 6260FR)
1
2
21 20
1 Darkness
2 ID Copy*
Scan to**
3 Display Screen
4 Fax*
5 Copy*
6 Arrows
7 OK
8 Numeric Keypad
9 Address Book
10 Redial/Pause*
Copyright© 1995-2012 SAMSUNG. All rights reserved.
4
3 5
19
18 17 16
Adjusts the brightness level to make a copy for easier reading, when the original
contains faint markings and dark images.
Allows you to copy both sides of an ID card like a driver's license on a single
side of paper.
Sends scanned data.
Shows the current status and prompts during an operation.
Switches to Fax mode.
Switches to Copy mode.
Scroll through the options available in the selected menu, and increase or
decrease values.
Confirms the selection on the screen.
Dials a number or enters alphanumeric characters.
Allows you to store frequently used fax numbers or search for stored fax numbers.
Redials the recently sent fax number or received caller ID in ready mode, or
inserts a pause(-) into a fax number in edit mode.
6 8
7
15
