2. Product specification and description
No.
Description
S9
Photo interrupter (Drive OPC sensor)
S10
Photo interrupter (MP Pickup sensor)
S11
Switch Front Cover (Cover Front Open sensor)
S12
Photo interrupter (MP Feed sensor)
S13
Photo interrupter (ITB sensor)
S14
Photo interrupter (Empty sensor)
S15
Photo interrupter (WTB Open sensor)
S16
Photo interrupter (Regi. sensor)
S17
Photo interrupter (Fuser Cam sensor)
S18
Photo interrupter (Binfull sensor)
S19
Photo interrupter (Fuser Exit sensor)
S20
Switch Rear Cover (Cover Rear Open sensor)
2-43
Controller
Main Board
Main Board
HVPS
Main Board
Main Board
Main Board
Main Board
Main Board
Main Board
Main Board
Main Board
HVPS
Copyright© 1995-2012 SAMSUNG. All rights reserved.
Function
Drive OPC detection
MP Pickup detection
Cover Open detection
MP Feed detection
ITB detection
Empty detection
WTB Open detection
Paper Feed detection
Fuser Cam detection
Binfull detection
Fuser Exit detection
Cover Open detection
