4.2.4. Other errors

1) Multi-feeding
•
Description : Multiple sheet of paper are fed at once.
Check and cause
Pick clutch or Regi clutch does not work properly.
Pick up/ Forward / Retard roller is worn out or contaminated.
2) No-Power
•
Description : When system power is turned on, LED and LCD on the operator panel do not come on.
Check and cause
The connection between main board and OPE board is bad.
HVPS/SMPS output is abnormal.
3) Calibrating the touch screen (Touch screen model only)
•
Description : Touch screen does not operate properly.
Check and cause
The linearity value for touch panel has changed due to using
a machine long hours or surroundings.
Copyright© 1995-2012 SAMSUNG. All rights reserved.
Solution
Replace the defective clutch if necessary.
Clean or replace the defective roller.
Solution
Reconnect or replace the harness.
Replace the HVPS/SMPS board.
Solution
1) Turn off the machine.
2) While pressing the number 0 on numeric keys, turn the
machine on. Wait until calibration screen appears.
3) Press centre of mark + following order 1~9. Use your
finger. Perform 2 times.
4) If there is no problem, "Complete" will appear on LCD
and reboot the machine. When making a mistake, start
again from the step 1.
4. Alignment and Troubleshooting
4-67
