3. Disassembly and Reassembly

3.2. Screws used in the printer

The screws listed in the table below are used in this printer. Please ensure that, when you disassemble the printer, you keep
a note of which screw is used for which part and that, when reassembling the printer, the correct screws are used in the
appropriate places.
NOTE
This list is based on CLX-6260FW. So, this list may differ from your machine depending on its model.
Parts Code Location
6002-000440 FUSER
6003-000269 FUSER
6003-000269 FRAME BASE
6002-000440 FRAME-LEFT
6003-000269 FRAME-LEFT
FRAME-GUIDE
6002-000440
CST L
FRAME-CRUM
6002-000440
HOLDER
6002-000440 FRAME-RIGHT
6003-000269 FRAME-RIGHT
FRAME-GUIDE
6002-000440
CST R
FRAME-BRACKET
6003-000269
OPC R
6003-000269 DRIVE-EXIT
FRAME-BRACKET
6003-000269
MP
6003-000196 FRAME-EXIT
6003-000196 FRAME MAIN
6003-000214 FRAME MAIN
6003-000269 FRAME MAIN
6003-000196 FRAME-RETARD
6003-000282 FRAME-RETARD
FRAME-SUPPORT
6003-000196
MAINBOARD
FRAME-SUPPORT
6003-000269
MAINBOARD
FRAME-POWER
6003-000301
SWITCH
6003-000269 DRIVE-MAIN
6003-000301 DRIVE-MAIN
6009-001697 DRIVE-MAIN
6003-000269 DRIVE-FUSER
6003-000269 DRIVE-PH
3-3
Description
SCREW-TAPPING;PWH,+,2,M3,L8,ZPC(BLK),SWRCH18A
SCREW-TAPTYPE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,-
SCREW-TAPTYPE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,-
SCREW-TAPPING;PWH,+,2,M3,L8,ZPC(BLK),SWRCH18A
SCREW-TAPTYPE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,-
SCREW-TAPPING;PWH,+,2,M3,L8,ZPC(BLK),SWRCH18A
SCREW-TAPPING;PWH,+,2,M3,L8,ZPC(BLK),SWRCH18A
SCREW-TAPPING;PWH,+,2,M3,L8,ZPC(BLK),SWRCH18A
SCREW-TAPTYPE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,-
SCREW-TAPPING;PWH,+,2,M3,L8,ZPC(BLK),SWRCH18A
SCREW-TAPTYPE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,-
SCREW-TAPTYPE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,-
SCREW-TAPTYPE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,-
SCREW-TAPTYPE;PWH,+,B,M3,L10,NI PLT,SWRCH18A
SCREW-TAPTYPE;PWH,+,B,M3,L10,NI PLT,SWRCH18A
SCREW-TAPTYPE;PH,+,WP,B,M3,L8,ZPC(WHT),SWRCH18A,-
SCREW-TAPTYPE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,-
SCREW-TAPTYPE;PWH,+,B,M3,L10,NI PLT,SWRCH18A
SCREW-TAPTYPE;BH,+,-,B,M3,L8,ZPC(BLK),SWRCH18A,-
SCREW-TAPTYPE;PWH,+,B,M3,L10,NI PLT,SWRCH18A
SCREW-TAPTYPE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,-
SCREW-TAPTYPE;BH,+,S,M4,L6,ZPC(WHT),SWRCH18A
SCREW-TAPTYPE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,-
SCREW-TAPTYPE;BH,+,S,M4,L6,ZPC(WHT),SWRCH18A
SCREW-SPECIAL;PH,+,M3,L4.4(3),NI PLT,SWRCH18A,MACH,2 BODY
SCREW-TAPTYPE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,-
SCREW-TAPTYPE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,-
Copyright© 1995-2012 SAMSUNG. All rights reserved.
Qty
2
7
45
12
16
2
8
3
27
1
1
1
13
1
5
1
57
2
1
1
1
1
20
6
1
4
2
