2. Product specification and description
•
Connection
1
2
3
4
BLU PBA (Back Light Unit)
This board is located over the LCD and functions the Back Light. It is included in LCD Assy and is assembled to OPE
controller.
•
Information
-
Part Code : JC92–02523A
-
PBA Name : BLU
•
Connection
1
2-31
FFC Connector to 4 line LCD
Interface connector to main controller
Interface connector to BLU (Back Light Unit) PBA
Interface connector to Scanner Home Sensor
Interface Connector To OPE PBA
