4. Alignment and Troubleshooting
Depth 1
106-Developer
107-Transfer
109-Fixing
110-LSU
-
Copier > Test Routines : This menu performs test routines for the engine.
Depth 1
100-Motor
101-Clutch
4-28
Depth 2
0000-Deve DC Yellow
0010-Deve DC Magenta
0020-Deve DC Cyan
0030-Deve DC Black
0121-Yellow Blade DC
0122-Magenta Blade DC
0123-Cyan Blade DC
0124-Black Blade DC
0030-STransfer1 High Voltage
0080-Transfer2 High Voltage
0010-Run Temperature offset
0040-LD Power Yellow
0050-LD Power Magenta
0060-LD Power Cyan
0070-LD Power Black
Depth 2
0020-K OPC Motor
0030-K OPC Motor Rdy
0040-Color OPC
0050-Color OPC Rdy
0120-Exit Mot Fwd
0131-Exit Mot Bwd
0260-SMPS Fan
0340-Feed Mot
0360-ITB Tension Release Motor
0000-MP Feed Clutch
0010-Tray1 Pickup
0020-Tray2 Pickup
0050-Registration
0070-Dup Gate
0090-Tray2 Feed
0130-Tray2 Feed Mot
0131-Tray2 Feed Mot Slow
0171-Front cover open
0190-OutBin Full
0230-T2 Nip Release
0240-DR Nip Release
0250-Knock Up Plate
