2.2.2. Rear View

NOTE
• This illustration may differ from your machine depending on your model. There are various types of machine.
• Some features and optional goods may not be available depending on model or country.
9 10
8
7
6
5
4
1 Waster toner container
2 Rear cover
3 Rear cover handle
4 Power receptacle
5 Power-switch
6 5V output port for IEEE 1284 parallel connector*
NOTE
* The optional IEEE 1284 parallel connector can be used by plugging in both the USB port and the 5V output port.
** CLX-626xFD/ CLX-626xFR/ CLX-626xFW Series only.
Copyright© 1995-2012 SAMSUNG. All rights reserved.
3
2
2. Product specification and description
1
1
7 USB port*
8 Network port
9 Telephone line socket (LINE)**
10 Extension telephone socket (EXT.)**
