Samsung CLX-6260FD Service Manual page 54

2. Product specification and description
No. Description
1 DADF-MOTOR
2 SOLENOID-DADF
3 SOLENOID-DADF
4 SOLENOID-LIFTING
5 PCB-DADF
6 SCAN-MOTOR
7 HVPS
8 Humidi.-Temp Sensor
9 PBA Waste Sensor
10 Power Inlet
11 Motor Step
12 Main Board
13 Motor Step
2-45
No. Description
14 Fan Type-5
15 PBA Wireless
16 Motor BLDC
17 PBA-HUB WIFI
18 Motor BLDC-BT6
19 Clutch-Electric Z41
20 SMPS
21 Fan Type-1
22 Clutch-Electric Z41
23 Clutch-Electric Z41
24 Solenoid MP
25 Clutch-Electric Z41
