2. Product specification and description
[OPE controller image]
•
Information
-
Part Code : JC95–02505A
-
PBA Name : 4.3 inch OPE Main
•
Connection
1
2
3
4
[OPE Key PBA]
2-33
FFC connector to OPE Key PBA
USB Interface connector to main controller
Interface connector to scanner home sensor
FFC Interface connector to 4.3 inch touch LCD
