Authorized Information; Notes - DigiTech DigiGate-700 User Manual

3 - 6
Figure 3-9

Authorized Information

1. This activates a screen where you can add other
users of the unit who will have a different
Access Number . Figure 3-9.
2. Enter the First Name and Last Name in the
appropriate fields.
3. Enter a unique Access Number .
4. Select a Keypad Zone and a Time Zone from
the list boxes.
NOTE: The same system required fields also
apply to Other Authorized Tenants . These
are Last Name , Keypad Zone , Time Zone ,
and a unique Access Code .
5. Click the Add button to add the new tenant to
the list at the bottom of the screen. You can add
as many tenants as you choose to the unit.
6. When you are done, Click on the Notes tab.
****************************************
NOTE: If you have purchased the Picture
Option, see the "Options" section at the end of
this chapter for instructions on using the option.
***************************************
Operating Instructions
Figure 3-10

Notes

1. This activates a screen where you can keep any
other information you choose. Figure 3-10.
2. To add any Notes in the text area, Click in the
text area and type freely.
NOTE: There are two buttons just above the
text area. One appears as a calendar and will
insert the date at the cursor when Clicked. The
second is a clock and will insert the current time
at the cursor when Clicked.
3. When all the information has been entered,
Click on the OK button to add the new tenant(s)
and send the information to the DigiGate-700
for Windows System Controller. The tenant(s)
will then be able to use the Keypads to enter
your location.
OR
Click on the Cancel button. This opens the
Confirm window with a prompt "Cancel Move
In?" Click on the Yes button to return to the
Select Unit to Move In screen, Figure 3-2,
Page 3-2, without moving the tenant in. Click
on the No button to return to the Move In
Tenants screen. Figure 3-10.
DigiGate-700
for Windows
™ ®
