Gate (Operate The Gate) - DigiTech DigiGate-700 User Manual

3 - 24
Figure 3-46
The Gate option on the main menu opens one window and allows you to open the gate (run through normal
open/close sequence), hold the gate open (lock the gate in the open position), and close a gate that has been
held open.
Only two decisions need be made: which action to take, and which gate to take it on.
1. From the Main Menu , Click on the Gate
button. Figure 3-46.

Gate (Operate the Gate)

2. This will open the Open Gates window.
Figure 3-47.
3. The Select action to perform radio buttons
have three options: Open , Hold Open , and
Close which are described above. Select one
of these. Figure 3-47.
Operating Instructions
Figure 3-47
DigiGate-700
for Windows
™ ®
