Arm/Disarm Unit; Acknowledge Or Arm/Disarm Selected Alarm Zones - DigiTech DigiGate-700 User Manual

4 - 12

Acknowledge or Arm/Disarm Selected Alarm Zones

1. From the Main Menu , Click on the Arm/Disarm button to open the Arm/Disarm Alarm Zones
window with the Alarm Zones tab active.
2. Select the Action you want to perform.
3. Select (checked) or deselect (unchecked) the Alarm Zones check boxes you want.
4. The All and None buttons will Select or Clear all the check boxes respectively.
NOTE: If an alarm is sounding, Selecting Acknowledge and Clicking on OK will turn the siren off
and reset the alarm zone. Selecting the Arm or Disarm selected Alarm Zone will perform the stated
function when OK is Clicked on this screen.
The two tabs, Alarm Zones and Arm/Disarm Unit are independent screens. OK must be Clicked on
the active screen to perform the desired action. Clicking OK on the Alarm Zones screen has NO effect
on the Arm/Disarm Unit screen and vice versa.
5. When all selections have been made, Click on the OK .
NOTE: See Page 3-72 in Chapter 3.
1. From the Main Menu , Click on the Arm/Disarm button to open the Arm/Disarm Alarm Zones
window with the Alarm Zones tab active.
2. Click on the Arm/Disarm Unit tab to work with individual or groups of units.
3. In the Options area, Select One Unit and type a unit number in the Unit field to arm or disarm a single
unit.
OR
Select the Vacant option under Options to specify all vacant units or Rented and Vacant to specify
ALL units.
4. Select Arm or Disarm from the Alarm Status list box.
5. When all selections have been made, Click on the OK button to perform the action.
6. Click on the Yes button in the Confirm window to perform the action.
NOTE: See Page 3-73 in Chapter 3.

Arm/Disarm Unit

How Do I ...?
DigiGate-700
for Windows
™ ®
