DigiGate-700 for Windows
™
1. Click on the Unit Setup tab of the Setup Menu , then Click on the Delete Units button.
2. To delete a consecutively numbered group of units, Select the Starting Unit Number field and type in
the first unit number in the group.
3. Select the Ending Unit Number field and type in the last unit number in the group.
NOTE: To delete one unit, enter the same number in the Starting Unit Number and the Ending Unit
Number fields.
4. Click on the Delete button to remove the unit(s) from the database or on the Cancel button to abandon
this operation and return to the Setup Menu .
5. Clicking on the Delete button, opens the Confirm window with the prompt of "Delete Units?"
6. Click on the Yes button to delete these units.
NOTE: See Page 2-40 in Chapter 2.
1. Click on the Unit Setup tab of the Setup Menu , then Click on the Modify Units button.
2. This will open the Modify Unit Information window.
NOTE: The Modify Unit Information window is a grid. Each row in the grid is a unit.
3. Select a unit, (row in the grid) and Click the Edit button to modify unit information.
1. From the Modify Unit (number) window with the Size tab active Select the proper size description
from the list box.
1. For Unit Type , Door Type , Floors , or Inside/Outside , Click on the Misc tab and Select the proper
descriptions from the list boxes. Click on the proper Inside or Outside selection.
1. For Feature 1 , Feature 2 , or Feature 3 , Click on the Features tab and Select the proper feature(s)
from the appropriate list box(es).
1. Click on the Door Alarm tab.
2. Open the Mux list box and Select the correct board.
3. Increase or decrease the number in the Slot field with the Up or Down arrows on the right.
4. Select the Alarm Zone list box and Select the correct zone for this unit.
5. Open the Unit Alarm Status list box and Select the correct status for this unit.
NOTE: See Page 2-41 in Chapter 2.
DigiGate-700
for Windows
™
- User's Guide
®

Delete Units

Modify Units

Size

Misc

Features

Door Alarms

®
4- 5
