Remove - DigiTech DigiGate-700 User Manual

3 - 62
Figure 3-129
1. From the Utility Menu with the Data Utilities
tab active, Click on the Remove button.
Figure 3-129.
Figure 3-130
Figure 3-131

Remove

2. This will open the Delete Data window.
Figure 3-130.
3. You can Select (Check) or Deselect (Uncheck)
either of the databases, Activity Log or
Transaction Log .
4. To change the date, select the month, day, or
year and type your choice or Click on the down
arrow to the right of the Date field.
Figure 3-130.
5. This will open the calendar. Figure 3-131. The
current date is shown at the bottom of the
window.
6. At the top of the window are left and right
arrow buttons. Click on these to change the
month, backward and forward, respectively.
7. Click on the correct day.
8. All records, up to and including the date chosen,
will be deleted.
Operating Instructions
DigiGate-700
for Windows
™ ®
