Add Units; Unit Numbers; Unit Size Information; Misc Unit Information - DigiTech DigiGate-700 User Manual

4 - 4
1. Click on the Unit Setup tab of the Setup Menu , then Click on the Add Units button.
2. To add a consecutively numbered group of units, Select the Starting Unit Number field and
type in the first unit number in the group.
3. Select the Ending Unit Number field and type in the last unit number in the group.
4. If you do not have Required Fields for this group, Click on the OK button. The Add Unit
Progress bar will reflect the units being added. Otherwise continue with the following steps.
1. If you selected Unit Size as a required field, Click on the Size tab and Select the proper size
description from the Size list box. The Square Feet , Height , and Price fields will display
the information you entered earlier in the set up procedure.
1. If you selected Unit Type , Door Type , Floors , or Inside/Outside as required fields,
Click on the Misc tab and Select the proper descriptions from the appropriate list boxes. If
necessary, Click on the proper Inside or Outside selection.
1. If you selected Feature 1 , Feature 2 , or Feature 3 as Required Fields, Click on the
Features tab and Select the proper features from the appropriate list boxes.
1. If all of the units in the group you are adding have individual Door Alarms, Click on the Door
Alarm tab.
2. Select the Mux list box and from the list of boards, Select the correct board.
3. After a Mux board has been selected, the Slot field will be activated. Until the board
selection, this field is deactivated and cannot be selected. Use the Up or Down arrows at the
right side of the box to increase or decrease the number in the Slot field. This number is the
starting number for the group of units you are adding.
4. Select the Alarm Zone list box and from the list of boards, Select the correct zone for this
unit. Normally there is only one Zone "Door Alarms."
5. If you are loading multiple units that have slot numbers in some sequence respective to the
unit numbers, select one of the choices { Increase | Decrease } and the value to increment
BY in the Auto Slot Loading Options area.
6. Click OK to add the units or Cancel to abandon the operation.
NOTE: See Page 2-37 in Chapter 2.

Add Units

Unit Numbers

Unit Size Information

Misc Unit Information

Unit Features

Door Alarm Options

How Do I ...?
DigiGate-700
for Windows
™ ®
