Misc Reports; Mux/Slot - DigiTech DigiGate-700 User Manual

3 - 44
Figure 3-89
This section shows how to run the Misc Reports and looks at the format of each report. The controls for
each of the reports in the display window are identical and have been explained completely at the beginning
of this chapter. When the Report Menu opens, the Unit Reports tab is active. Click on the Misc
Reports tab to activate it.
1. From the Main Menu , Figure 3-46, Page 3-24,
Click on the Report button to open the Report
Menu window. Click on the Misc Reports
tab. Figure 3-89.
2. Click on the Mux/Slot button.
NOTE: This report is only valid for sites that
have individual Door Alarms.

Misc Reports

Mux/Slot

3. This will open the report display window with
the title of Mux/Slot Report and run the
Mux/Slot Report. Figure 3-90.
4. The columns displayed are: Unit Number,
Mux Number, Slot, and Status. (A for
Armed or D for Disarmed)
5. There are no totals for this report.
6. Click on the Close button to return to the
Report Menu .
Operating Instructions
Figure 3-90
DigiGate-700
for Windows
™ ®
