DigiTech DigiGate-700 User Manual page 42

2 - 14
Figure 2-26
12. The Default Security Level list box holds all
of the security levels that were set up earlier in
this section. If the User IDs is activated, this
selection will be used as the default level for
any new users you add. Figure 2-26.
13. To set the Default Security Level , Click on
the text area or the down arrow at the right side
of text area to open the list.
14. Click on the level you want as default.
15. The list will close and your selection will be
displayed.
16. The Select Backup Set field contains
"SiteOne.set" in the directory specified in
the program installation. This file is predefined
and included with the shipped program.
NOTE: The DigiGate-700 for Windows
program uses Microsoft Backup, which MUST
be installed on your computer before you can
use the DigiGate backup function.
Setting Up a New Site
Figure 2-27
17. Clicking on the folder at the right side of this
field opens the Windows 95/98 Browse window.
Figure 2-27. You MUST be familiar with
creating Windows backup sets or jobs to use
any other than the default selection.
NOTE: See Chapter 5, Backing Up Your
Data, for additional information on Backup Sets
and using other backup programs on your
system.
18. When all System Configuration fields have
been set as you want them, Click on the OK
button to accept the choices, or on the Cancel
button to discard selections and return to the
Setup Menu .
DigiGate-700
for Windows
™ ®
