7.5.3.4
Config | Redundancy
Appendix A. REDUNDANT SYSTEM OPERATION
Use this page to configure the units Redundancy Switch Mode.
Reundancy
Click [Refresh] to update screen.
Name
Redundancy State
Redundancy Mode
Force Backup
Converter A Status
Converter B Status
Ethernet Interface Operation
Figure 7-14. 'Config | Redundancy' Page
Use the drop-down menu to select Enable or Disable. Click [Change] to update
settings.
Use the drop-down menu to select Manual or Auto. Click [Change] to update
settings.
Use the drop-down menu to select Yes or No. Click [Change] to update settings.
This read-only showing Online or Offline.
This read-only showing Online or Offline.
7–20
LBC-4000 L-Band Up/Down Converter System
Description
Revision 6
MN-LBC-4000
