MBT-5000A
L-Band Up/Down Converter System
Installation and Operation Manual
Part Number MN-MBT-5000A
Revision 1
Firmware Version 1.1.3
IMPORTANT NOTE: The information contained in this document supersedes all previously published
information regarding this product. Product specifications are subject to change without prior notice.
