Icom ic-7700 Instruction Manual page 94

5
FUNCTIONS FOR RECEIVE
D Scope set mode (continued)
Waterfall Display
Set the waterfall display to ON or OFF.
Waterfall Peak Color Level
The signal level that reaches a peak color is set to
Grid 1 to Grid 8 for the waterfall display.
Higher signal levels are Red, Yellow, Green, Light-
blue, Blue and Black in order.
Sweep Speed (± 2.5k)
Select the sweep speed for the ±2.5 kHz span
selection from SLOW, MID and FAST.
(±
Select the sweep speed for the ±5 kHz span selec-
tion from SLOW, MID and FAST.
(±
Select the sweep speed for the ±10 kHz span selec-
tion from SLOW, MID and FAST.
(±
Select the sweep speed for the ±25 kHz span selec-
tion from SLOW, MID and FAST.
(±
Select the sweep speed for the ±50 kHz span selec-
tion from SLOW, MID and FAST.
(± 100k)
Select the sweep speed for the ±100 kHz span
selection from SLOW, MID and FAST.
(± 250k)
Select the sweep speed for the ±250 kHz span
selection from SLOW, MID and FAST.
5k)
10k)
25k)
50k)
ON
• ON : Displays the waterfall of the spectrum scope.
• OFF : Does not display the waterfall.
Grid 8
MID
NOTE: Signals may be displayed incorrectly with
"FAST" setting.
MID
NOTE: Signals may be displayed incorrectly with
"FAST" setting.
FAST
FAST
FAST
FAST
FAST
5-6
