D Command table (continued)
Cmd. Sub Cmd. Data
1A 05 0001 see p. 12-4 Send/read SSB RX HPF/LPF
0002 00 to 10
0003 00 to 10
0004 see p. 12-4 Send/read AM RX HPF/LPF
0005 00 to 10
0006 00 to 10
0007 see p. 12-4 Send/read FM RX HPF/LPF
0008 00 to 10
0009 00 to 10
0010 see p. 12-5 Send/read CW RX HPF/LPF
0011 see p. 12-5 Send/read RTTY RX HPF/LPF
0012 see p. 12-5 Send/read PSK RX HPF/LPF
0013 00 to 10
0014 00 to 10
0015 00 to 10
0016 00 to 10
0017 00 to 10
0018 00 to 10
0019 see p. 14-12 Send/read SSB TX bandwidth for wide
0020 see p. 14-12 Send/read SSB TX bandwidth for mid
0021 see p. 14-12 Send/read SSB TX bandwidth for
0022 0000 to
0255
0023 0000 to
0255
0024 00/01
0025 0000 to
0255
0026 00/01
0027 0000 to
0255
Description
( HPF: 0=Through, 1=100 to 20=2000,
LPF: 5=500 to 24=2400, 25=Through)
Send/read SSB RX Tone (Bass) level
(00 =–5 to 10=+5)
Send/read SSB RX Tone (Treble) level
(00=–5 to 10=+5)
(HPF: 00=Through, 01=100 to
20=2000, LPF: 5=500 to
24=2400, 25=Through)
Send/read AM RX Tone (Bass)
level (00 =–5 to 10=+5)
Send/read AM RX Tone (Treble)
level (00=–5 to 10=+5)
(HPF: 00=Through, 01=100 to
20=2000, LPF: 5=500 to
24=2400, 25=Through)
Send/read FM RX Tone (Bass)
level (00 =–5 to 10=+5)
Send/read FM RX Tone (Treble)
level (00=–5 to 10=+5)
(HPF: 00=Through, 01=100 to
20=2000, LPF: 5=500 to
24=2400, 25=Through)
(HPF: 00=Through, 01=100 to
20=2000, LPF: 5=500 to
24=2400, 25=Through)
(HPF: 00=Through, 01=100 to
20=2000, LPF: 5=500 to
24=2400, 25=Through)
Send/read SSB TX Tone (Bass) level
(00 =–5 to 10=+5)
Send/read SSB TX Tone (Treble) level
(00=–5 to 10=+5)
Send/read AM TX Tone (Bass) level
(00 =–5 to 10=+5)
Send/read AM TX Tone (Treble) level
(00=–5 to 10=+5)
Send/read FM TX Tone (Bass)
level (00 =–5 to 10=+5)
Send/read FM TX Tone (Treble)
level (00=–5 to 10=+5)
narrow
Send/read speech level
(0000=0% to 0255=100%)
Send/read CW side tone gain
(0000=min. to 0255=max.)
Send/read CW side tone gain limit
(00=OFF, 01=ON)
Send/read beep gain
(0000=min. to 0255=max.)
Send/read beep gain limit
(00=OFF, 01=ON)
Send/read headphones output
ratio (0000=0.60 to 0255=1.40)
Cmd. Sub Cmd. Data
1A 05 0028 0000 to
0255
0029 0000 to
0255
0030 0000 to
0255
0031 0000 to
0255
0032 00 to 03
0033 00 to 03
0034 00 to 03
0035 00 to 03
0036 00/01
0037 00 to 07
0038 0000 to
0255
0039 00 to 02
0040 0000 to
0255
0041 0000 to
0255
0042 0000 to
0255
0043 00 to 01
0044 00 to 04
0045 00 to 02
0046 00 to 02
0047 00/01
0048 00/01
0049 00/01
0050 00/01
0051 00/01
0052 00 to 03
14-5
CONTROL COMMAND
Description
Send/read AF output level to ACC
(0000=0% to 0255=100%)
Send/read S/P DIF output level
(0000=0% to 0255=100%)
Send/read MOD output level to
ACC (0000=0% to 0255=100%)
Send/read S/P DIF MOD output
level (0000=0% to 0255=100%)
Send/read MOD input connector
during DATA OFF
( 00=MIC; 01=ACC; 02=MIC/ACC;
03=S/P DIF; 04=LAN)
Send/read MOD input connector
during DATA1
( 00=MIC; 01=ACC; 02=MIC/ACC;
03=S/P DIF; 04=LAN)
Send/read MOD input connector
during DATA2
( 00=MIC; 01=ACC; 02=MIC/ACC;
03=S/P DIF; 04=LAN)
Send/read MOD input connector
during DATA3
( 00=MIC; 01=ACC; 02=MIC/ACC;
03=S/P DIF; 04=LAN)
Send/read relay type selection
(00=Reed, 01=MOS-FET)
Send/read external meter output
selection
(00=Auto, 01=S, 02=Po, 03=SWR,
04=ALC, 05=COMP, 06=VD, 07=ID)
Send/read external meter output
level (0000=0% to 0255=100%)
Send/read reference signal in/out
setting (00=IN, 01=OFF, 02=OUT)
Send/read reference signal frequency
setting (0000=0% to 0255=100%)
Send/read LCD unit backlight
brightness (0000=0% to 0255=100%)
Send/read switch indicator brightness
(0000=1 to 0255=100)
Send/read screen image type
(00=A, 01=B)
Send/read frequency readout font
(00=Basic (1), 01=Basic (2), 02=Italic,
03=Round, 04=Slim)
Send/read meter response setting
(00=SLOW, 01=MID, 02=FAST)
Send/read meter type
(00=Standard, 01=Edgewise, 02=Bar)
Send/read meter type during wide
screen or mini scope display
(00=Edgewise, 01=Bar)
Send/read peak hold set for Bar meter
(00=OFF, 01=ON)
Send/read memory name display
setting (00=OFF, 01=ON)
Send/read audio peak filter width
pop-up display setting
(00=OFF, 01=ON)
Send/read manual notch width
pop-up display setting
(00=OFF, 01=ON)
Send/read screen saver set
(0=OFF, 01=15 min., 02=30 min.,
03=60 min.)
