Icom ic-7700 Instruction Manual page 209

D Command table (continued)
Cmd. Sub Cmd. Data
1A 05 0224 00, 01
06 see p. 14-11 Send/read DATA mode with filter set
07 00
01
02
08 00
01
09 00
01
02
0A 00
01
02
1B 00 see p. 14-11 Send/read repeater tone frequency
01 see p. 14-11 Send/read TSQL tone frequency
1C 00 00
01
01 00
01
02
02 00, 01
03 see p. 14-10 Read transmit frequency
04 00
01
1E 00 –
01 see p. 14-12 Read TX band edge frequencies
02 –
03 see p. 14-12 Send/read user-set TX band edge
21 00 see p. 14-12 Send/read RIT frequency.
01 00, 01
02 00, 01
25 see p. 14-14 Send/read the selected or unselected
26 see p. 14-14 Send/read the selected or unselected
Description
Send/read antenna controller status
(frequency, and so on) data output
from [REMOTE] (00=OFF, 01=ON)
WIDE selection for SSB transmit
bandwidth
MID selection for SSB transmit
bandwidth
NAR selection for SSB transmit
bandwidth
SHARP selection for DSP filter type
SOFT selection for DSP filter type
3 kHz roofing filter selection
6 kHz roofing filter selection
15 kHz roofing filter selection
WIDE selection for manual notch width
MID selection for manual notch width
NAR selection for manual notch width
Send/read transceiver's status (RX)
When "CI-V Output (for ANT)"
(Command: 1C 04) is set to "ON,"
automatically outputs when changed.
Send/read transceiver's status (TX)
When "CI-V Output (for ANT)"
(Command: 1C 04) is set to "ON,"
automatically outputs when changed.
Antenna tuner OFF (through)
Antenna tuner ON
Tuning
Send/read transmit frequency monitor
setting (00=OFF, 01=ON)
When "CI-V Output (for ANT)"
(Command: 1C 04) is set to "ON,"
automatically outputs when changed.
Send/read command to disable to
output the antenna controller status
(frequency and so on) from [REMOTE].
Send/read command to enable to
output the antenna controller status
(frequency and so on) from [REMOTE].
Read number of available TX frequency
band
Read number of user-set TX frequency
band
frequencies
Send/read RIT setting.
(00=OFF, 01=ON)
Send/read ∂TX setting.
(00=OFF, 01=ON)
VFO frequency.
VFO's operating mode and filter.
14-9
