CONTROL COMMAND
D Command table (continued)
Cmd. Sub Cmd. Data
1A 05 0177 00/01
0178 00 to 02
0179 00/01
0180 00/01
0181 00 to 02
0182 00 to 20
0183 00 to 03
0184 00 to 09
0185 0000 to
0255
0186 00/01
0187 00/01
0188 00/01
0189 00/01
0190 00
01
02
03
04
05
0191 00 to 06 Send/read APF AF level.
0192 0000 to
0255
0193 00 to 05 Send/read the TX Delay setting (HF)
0194 00 to 05 Send/read the TX Delay setting (50M)
0195 00, 01
0196 0000 to
0223
0197
0198 00, 01
0199 000001 to
065535
0200 000001 to
065535
0201 000001 to
065535
Description
Send/read antenna temporary memory
set (00=OFF, 01=ON)
Send/read antenna selection
(00=OFF, 01=Manual, 02=Auto)
Send/read usage for ANT2
(00=OFF, 01=TX/RX)
Send/read usage for ANT3
(00=OFF, 01=TX/RX)
Send/read usage for ANT4
(00=OFF, 01=TX/RX, 02= RX)
Send/read VOX delay
(00=0.0 sec. to 20=2.0 sec.)
Send/read VOX voice delay
(00=OFF, 01=Short, 02=Mid., 03=Long)
Send/read NB depth (00=1 to 09=10)
Send/read NB width
(0000=0 to 0255=255)
Send/read external keypad set
for RTTY memory (00=OFF, 01=ON)
Send/read external keypad set
for PSK memory (00=OFF, 01=ON)
Voice memory transmission set for
[F1]– [F4] on the keyboard (00=OFF,
01=ON)
Memory keyer transmission set for [F1]–
[F4] on the keyboard (00=OFF, 01=ON)
Send/read time-out timer OFF
Send/read 3 min. time-out timer
Send/read 5 min. time-out timer
Send/read 10 min. time-out timer
Send/read 20 min. time-out timer
Send/read 30 min. time-out timer
(00=0 dB to 06=+6dB)
Send/read LAN MOD output level
(0000=0% to 0255=100%)
( 00=OFF, 01=10 ms, 02=15 ms,
03=20 ms, 04=25 ms, 05=30 ms)
( 00=OFF, 01=10 ms, 02=15 ms,
03=20 ms, 04=25 ms, 05=30 ms)
Send/read the Shutdown function.
( 00=Shutdown, 01=Standby/Shut-
down)
Send/read the transceive CI-V Ad-
dress for LAN to REMOTE in hexa-
decimal code.
(0000=00h to 0223=DFh)
Send/read the default gateway set
( 0000000000000001=0.0.0.1 to 0255
025502550254=255.255.255.254, or
FF=Blank)
Send/read the remote control capabil-
ity. (00=OFF, 01=ON)
Send/read the control port setting by
accessing from internet.
(000001=1 to 065535=65535)
Send/read the serial port setting by
accessing from internet.
(000001=1 to 065535=65535)
Send/read the audio port setting by
accessing from internet.
(000001=1 to 065535=65535)
Cmd. Sub Cmd. Data
1A 05 0202 00, 01
0203 see p. 14-14 Send/read Network radio name
0204 00 to 04 Send/read the maximum AF sample
0205 00 to 02 Send/read the AF codecs for remote
0206 00, 01
0207 00 to 04 Send/read the maximum modulation
0208 00 to 02 Send/read the modulation codecs for
0209 00, 01
0210 see p. 14-11 Send/read the waveform outline color
0211 00, 01
0212 00 to 07 Send/read the peak color level for
0213 00, 01
0214 see p. 14-11 Send/read waveform color for Audio
0215 00, 01
0216 see p. 14-11 Send/read waveform color for Audio
0217 00, 01
0218 01 to 15 Send/read the repeat interval to
0219 00, 01
0220 00, 01
0221 00, 01
0222 00, 01
0223 00 to 03 Send/read QSO PLAY Skip time.
