Options - Icom ic-7700 Instruction Manual

15
SPECIFICATIONS AND OPTIONS

■ Options

• IC-PW1/EURO
/50 z 1 k
hf mh all band
Full-duty-cycle 1 kW linear amplifier including an
automatic antenna tuner. Has automatic tuning and
band selection capability when used with an Icom
transceiver. Full break-in (QSK) operation. The
amplifier/power supply unit and the remote control
unit can be separately installed.
• SM-50
desktop microphone
• HM-36
hand microphone
SP-33
external speaker
Designed for base station operation.
: 8 Ω
• Input impedance
• Max. input power : 5 W
RS-BA1
ip remote control software
To remotely control radios using the RS-BA1, BE SURE
that you comply with your local regulations.
Approved Icom optional equipment is designed for optimal performance when used with an Icom transceiver.
Icom is not responsible for the destruction or damage to an Icom transceiver in the event the Icom transceiver is
used with equipment that is not manufactured or approved by Icom.
w linear amplifier
Unidirectional, dynamic
microphone for base sta-
tion operation. Includes
[UP]/[DOWN] switches, a
low cut switch and mic gain
control.
Hand microphone equipped
with [UP]/[DOWN] switches.
SP-34
external speaker
4 audio filters; headphone jack; can connect to 2 transceiv-
ers.
• Input impedance
• Max. input power
• SM-30
desktop microphone
• CT-17
-
ci v level converter
This unit converts signal levels from RS-232C data
to the serial CI-V data. This can be used for remote
transceiver control using PC. You can change fre-
quencies, operating mode, memory channels, etc.
(software is not included)
15-4
: 8 Ω
: 5 W
Unidirectional, electret micro-
phone for base station opera-
tion. Includes low cut switch
and mic gain control.
