Icom ic-7700 Instruction Manual page 181

■ Other set mode
Keyboard Repeat Delay
Sets the time period for delay from 100 to 1000 mil-
liseconds in 50 millisecond steps. (default: 250 mil-
liseconds)
When a key of the connected keyboard is held down
for the set period, the character is input continuously.
Keyboard Repeat Rate
Sets the repeating rate for the connected keyboard
within 2.0 to 30.0 cps. (default: 10.9 cps)
When a key of the connected keyboard is held down,
the character is repeatedly input with the set speed.
IP Address
Sets IP address for the IC-7700 when connecting to
your PC or LAN (Local Area Network) through the
Ethernet connector.
Subnet Mask
Sets subnet mask for the IC-7700 when connecting
to your PC or LAN (Local Area Network) through the
Ethernet connector.
Default Gateway
Sets the default gateway of the router that you want
to connect the IC-7700 to.
Only when you configure the remote control sys-
tem using an optional RS-BA1 through the Inter-
net, you need this setting.
Network Control
Selects the remote control capability ON or OFF.
(default : OFF)
Only when you configure the remote control sys-
tem using an optional RS-BA1, you need this set-
ting.
Control Port (UDP)
Sets the Control port of the IC-7700 by accessing
from the remote station.
Only when you configure the remote control sys-
tem using an optional RS-BA1, you need this set-
ting.
(continued)
*cps=character per second
(Valid after Reboot)
(Valid after Reboot)
(Valid after Reboot)
(Valid after Reboot)
(Valid after Reboot)
250ms
10.9cps
• Available repeating rate
2.0, 2.1, 2.3, 2.5, 2.7, 3.0, 3.3, 3.7, 4.0, 4.3, 4.6, 5.0,
5.5, 6.0, 6.7, 7.5, 8.0, 8.6, 9.2, 10.0, 10.9, 12.0,
13.3, 15.0, 16.0, 17.1, 18.5, 20.0, 21.8, 24.0, 26.7,
30.0
192. 168.
Turn the transceiver power OFF then ON to make
the setting effective. See page 16-7 for details.
255. 255. 255.
Turn the transceiver power OFF then ON to make
the setting effective. See page 16-7 for details.
. .
Turn the transceiver power OFF then ON to make
the setting effective.
OFF
Turn the transceiver power OFF then ON to make
the setting effective.
50001
Turn the transceiver power OFF then ON to make
the setting effective.
12-19
SET MODE
0. 10
0 (24bit)
.
12
