Icom ic-7700 Instruction Manual page 207

D Command table (continued)
Cmd. Sub Cmd. Data
1A 05 0113 00 to 02
0114 00 to 02
0115 see p. 14-11 Send/read scope edge frequencies
0116 see p. 14-11 Send/read scope edge frequencies
0117 see p. 14-11 Send/read scope edge frequencies
0118 see p. 14-11 Send/read scope edge frequencies
0119 see p. 14-11 Send/read scope edge frequencies
0120 see p. 14-11 Send/read scope edge frequencies
0121 see p. 14-11 Send/read scope edge frequencies
0122 see p. 14-11 Send/read scope edge frequencies
0123 see p. 14-11 Send/read scope edge frequencies
0124 see p. 14-11 Send/read scope edge frequencies
0125 see p. 14-11 Send/read scope edge frequencies
0126 see p. 14-11 Send/read scope edge frequencies
0127 00/01
0128 03 to 10
0129 05 to 15
0130 00
01
02
03
04
0131 01 to 04
0132 0001 to
9999
0133 01 to 60
0134 28 to 45
0135 00 to 03
0136 00/01
0137 00 to 02
0138 00/01
0139 00 to 03
0140 see p. 14-11 Send/read FFT scope waveform
0141 00/01
Description
Send/read scope sweep speed for ±100
kHz span (00=Slow, 01=Mid., 02=Fast)
Send/read scope sweep speed for ±250
kHz span (00=Slow, 01=Mid., 02=Fast)
for 0.03 to 1.60 MHz band
for 1.60 to 2.00 MHz band
for 2.00 to 6.00 MHz band
for 6.00 to 8.00 MHz band
for 8.00 to 11.00 MHz band
for 11.00 to 15.00 MHz band
for 15.00 to 20.00 MHz band
for 20.00 to 22.00 MHz band
for 22.00 to 26.00 MHz band
for 26.00 to 30.00 MHz band
for 30.00 to 45.00 MHz band
for 45.00 to 60.00 MHz band
Send/read auto voice monitor set
(00=OFF, 01=ON)
Send/read voice memory short
play time (03=3 sec. to 10=10 sec.)
Send/read voice memory normal
record time (05= 5 sec. to 30=30 sec.)
Normal selection for contest number
style
" 190→ANO" selection for contest
number style
" 190→ANT" selection for contest
number style
" 90→NO" selection for contest number
style
" 90→NT" selection for contest number
style
Send/read count up trigger channel
(01=M1, 02=M2, 03=M3, 04=M4)
Send/read present number
(0001=1, 9999=9999)
Send/read CW keyer repeat time
(01=1 sec. to 60=60 sec.)
Send/read CW keyer dot/dash ratio
(28=1:1:2.8 to 45=1:1:4.5)
Send/read rise time
(00=2 msec., 01=4 msec.,
02=6 msec., 03=8 msec.)
Send/read paddle polarity
(00=Normal, 01=Reverse)
Send/read keyer type (00=Straight,
01=Bug-key, 02=ELEC-Key)
Send/read mic. up/down keyer set
(00=OFF, 01=ON)
Send/read FFT scope averaging set for
RTTY decoder
(00=OFF, 01=2, 02=3, 03=4)
color set for RTTY decoder
Send/read RTTY decode USOS
(00=OFF, 01=ON)
Cmd. Sub Cmd. Data
1A 05 0142 00/01
0143 00 to 02
0144 00/01
0145 00/01
0146 00/01
0147 00/01
0148 00/01
0149 see p. 14-11 Send/read received text font color
0150 see p. 14-11 Send/read transmitted text font color
0151 see p. 14-11 Send/read time stamp text font color
0152 see p. 14-11 Send/read text font color in TX buffer
0153 –
0154 see p. 14-11 Send/read FFT scope waveform
0155 00/01
0156 00/01
0157 00/01
0158 00/01
0159 see p. 14-11 Send/read received text font color for
0160 see p. 14-11 Send/read transmitted text font color
0161 see p. 14-11 Send/read time stamp text font color
0162 see p. 14-11 Send/read text font color in TX buffer
0163 00/01
0164 00/01
0165 see p. 14-12 Send/read antenna selection for
0166 see p. 14-12 Send/read antenna selection for
0167 see p. 14-12 Send/read antenna selection for
0168 see p. 14-12 Send/read antenna selection for
0169 see p. 14-12 Send/read antenna selection for
0170 see p. 14-12 Send/read antenna selection for
0171 see p. 14-12 Send/read antenna selection for
0172 see p. 14-12 Send/read antenna selection for
0173 see p. 14-12 Send/read antenna selection for
0174 see p. 14-12 Send/read antenna selection for
0175 see p. 14-12 Send/read antenna selection for
0176 see p. 14-12 Send/read antenna selection for
14-7
CONTROL COMMAND
Description
Send/read RTTY decode new line code
(00=CR,LF,CR+LF, 01=CR+LF)
Send/read RTTY diddle (00=OFF,
01=Blank, 02=LTRS (Letter code))
Send/read RTTY TX USOS
(00=OFF, 01=ON)
Send/read RTTY auto CR+LF by TX
(00=OFF, 01=ON)
Send/read RTTY time stamp set
(00=OFF, 01=ON)
Send/read clock selection for time
stamp(0=Local time, 1=CLOCK2)
Send/read frequency stamp
(00=OFF, 01=ON)
Send/read FFT scope averaging set for
PSK decoder
(00=OFF, 01=2, 02=3, 03=4)
color set for PSK decoder
Send/read PSK AFC function tuning
range (00=±8 Hz, 01=±15 Hz)
Send/read PSK time stamp set
(00=OFF, 01=ON)
Send/read clock selection for time
stamp (00=Local time, 01=CLOCK2)
Send/read frequency stamp
(00=OFF, 01=ON)
PSK decoder
(PSK)
(PSK)
(PSK)
Send/read scan speed
(00=Low, 01=High)
Send/read scan resume
(00=OFF, 01=ON)
0.03 to 1.60 MHz band
1.60 to 2.00 MHz band
2.00 to 6.00 MHz band
6.00 to 8.00 MHz band
8.00 to 11.00 MHz band
11.00 to 15.00 MHz band
15.00 to 20.00 MHz band
20.00 to 22.00 MHz band
22.00 to 26.00 MHz band
26.00 to 30.00 MHz band
30.00 to 45.00 MHz band
45.00 to 60.00 MHz band
14
