• Offset frequency setting
Command : 1A 05 0068, 0069, 0074
q w
X 0 X
*No need to enter for transverter offset frequency setting.
† Transverter offset only; Fix to '0' for split offset setting.
• Codes for memory name, opening
message and CLOCK2 name contents
- Character's code— Alphabetical characters
Character ASCII code
A–Z 41–5A
- Character's code— Symbols
Character ASCII code
! 21
$ 24
& 26
? 3F
' 27
^ 5E
− 2D
/ 2F
, 2C
; 3B
< 3C
( 28
[ 5B
{ 7B
| 7C
¯ 7E
Command Set item/available characters
1A 00 Memory name
All characters are available.
1A 050058 Opening message
Capital letters, numerals, some symbols (− / .
@) and space are available.
1A 050063 CLOCK2 name
Capital letters, small letters, numerals, some
symbols (! # $ % & \ ? " ' ` ^ + – ✱ / . , : ; = < >
( ) [ ] { } | _ ¯ @) and space are available.
e r*
X 0 X XX
Character ASCII code
a-z 61–7A
Character ASCII code
# 23
% 25
\ 5C
" 22
` 60
+ 2B
2A
✱
. 2E
: 3A
= 3D
> 3E
) 29
] 5D
} 7D
_ 5F
@ 40
• Color setting
Command : 1A 05 0106, 0107, 0140, 0149, 0150,
q w
0 X X X
R (Red)
0000–0255
• Bandscope edge frequency setting
Command : 1A 05 0115, 0116, 0117, 0118, 0119,
q w
X X X X X X X X X X X X
Lower edge
• Data mode with filter width setting
Command : 1A 06
q
X X X X
* When "00" is set, set "00" in w.
• Repeater tone/tone squelch frequency
setting
Command : 1B 00, 1B 01
q*
0 0
*Not necessary when setting a frequency.
14-11
CONTROL COMMAND
0151, 0152, 0154, 0159, 0160,
0161, 0162, 0210, 0214, 0216
e r t
0 X X X 0 X X X
G (Green) B (Blue)
0000–0255 0000–0255
0120, 0121, 0122, 0123, 0124,
0125, 0126
e r t
Higher edge
w
01=FIL1
02=FIL2
03=FIL3
00=Data mode OFF*
01=Data mode 1 (D1)
02=Data mode 2 (D2)
03=Data mode 3 (D3)
w e
X X X
14
y
y
X
