12
SET MODE
■ Level set mode
SSB TBW (WIDE)
Sets the transmission passband width to a wide
setting by changing the lower and higher cut-off fre-
quencies.
SSB TBW (MID)
Sets the transmission passband width to a middle
setting by changing the lower and higher cut-off fre-
quencies.
SSB TBW (NAR)
Sets the transmission passband width to a narrow
setting by changing the lower and higher cut-off fre-
quencies.

Speech Level

Sets the side tone output level from 0 to 100% in 1%
steps. (default: 50%)
Side Tone Level
Sets the side tone output level from 0 to 100% in 1%
steps. (default: 50%)
Side Tone Level Limit
Turns the side tone output level limiting capability
ON or OFF. (default: ON)
APF AF Level
Sets the audio level that the audio peak filter is ON
in the CW mode, from 0 to +6 dB in 1dB step.
(default: 0dB)
Beep Level
Sets the key-touch beep output level from 0 to 100%
in 1% steps. (default: 50%)

Beep Level Limit

Turns the key-touch beep output level limiting capa-
bility ON or OFF. (default: ON)
Phones Level Ratio
Sets the ratio for audio output level from the head-
phone toward to the internal speaker within a range
of 0.60 to 1.40 in 0.01 steps. (default: 1.00)
(continued)
100 – 2900
Lower freq. : 100 (default), 200, 300 and 500 Hz
Higher freq. : 2500, 2700, 2800 and 2900 Hz (de-
fault)
300 – 2700
Lower freq. : 100, 200, 300 (default) and 500 Hz
Higher freq. : 2500, 2700 (default), 2800 and 2900
Hz
500 – 2500
Lower freq. : 100, 200, 300 and 500 Hz (default)
Higher freq. : 2500 (default), 2700, 2800 and 2900
Hz
ON
ON
12-6
50 %
50 %
0dB
50 %
1.00
