14
CONTROL COMMAND
D Data contents description (continued)
• Codes for Network Radio name contents
Command : 1A 05 0203
- Character's code— Number
Character ASCII code
0–9 30–39
- Character's code— Alphabetical characters
Character ASCII code
A–Z 41–5A
- Character's code— Symbols
Character ASCII code
! 21
$ 24
& 26
" 22
` 60
+ 2B
2A
✱
. 2E
: 3A
= 3D
> 3E
) 29
] 5D
} 7D
_ 5F
@ 40
• Selected or unselected VFO's frequency
settings
Command : 25
X X X X X X X X X X 0 0
00: MAIN
Operating frequency data
01: SUB
(See p. 14-10)
Character ASCII code
Character ASCII code
a-z 61–7A
Character ASCII code
# 23
% 25
? 3F
' 27
^ 5E
− 2D
/ 2F
, 2C
; 3B
< 3C
( 28
[ 5B
{ 7B
| 7C
¯ 7E
• Selected or unselected VFO's operating
mode and filter settings
Command : 26
Both data and filter settings can be skipped. In that
case, "DATA OFF" and the default filter setting of the
operating mode is automatically selected.
00: Selected VFO
01: Unselected VFO
q Operating mode setting
q Operating mode
00: LSB 05: FM
01: USB 07: CW-R
02: AM 08: RTTY-R 02: Data mode 2 (D2) 03: FIL3
03: CW 12: PSK
04: RTTY 13: PSK-R
14-14
w Data mode setting
X X X X X X X X
e Filter setting
w Data mode e Filter
setting
00: Data mode OFF 01: FIL1
01: Data mode 1 (D1) 02: FIL2
03: Data mode 3 (D3)
setting
