SET MODE
■ ACC set mode
DATA2 MOD
Selects the desired connector(s) for modulation
input when data 2 mode (D2) is in use.
DATA3 MOD
Selects the desired connector(s) for modulation
input when data 3 mode (D3) is in use.
SEND Relay Type
Selects the switching relay type for [RELAY] from
Reed and MOSFET.
Select the suitable relay type when connecting a
non-Icom linear amplifier.
External Meter Output
Selects the desired item for an external meter indi-
cation.
External Meter Level
Sets the output level for an external meter indication
within 0 to 100% range in 1% steps.
(continued)
MIC,ACC
• MIC : Use the signals from [MIC].
• ACC : Use the signals from [ACC1] (pin 4).
• MIC,ACC : U s e t h e s i g n a l s f r o m [ M I C ] a n d
[ACC1] (pin 4). (default)
• S/P DIF : Use the signals from [S/P DIF].
• LAN : Use the signals from [LAN].
MIC
• MIC : Use the signals from [MIC]. (default)
• ACC : Use the signals from [ACC1] (pin 4).
• MIC,ACC : U s e t h e s i g n a l s f r o m [ M I C ] a n d
[ACC1] (pin 4).
• S/P DIF : Use the signals from [S/P DIF].
• LAN : Use the signals from [LAN].
MOS-FET
• Reed : Use mechanical relay.
(16 V DC/0.5 A maximum)
• MOS-FET: Use semiconductor type relay.
(250 V/200 mA
Auto
• Auto : Outputs the receiving signal strength
level during receive, and outputs the
selected level (selected with [METER]),
during transmit. (default)
• S : Outputs the receiving signal strength
level during receive.
• Po : Outputs the transmitting power level dur-
ing transmit.
• SWR : Outputs the VSWR level during transmit.
• ALC : Outputs the ALC level during transmit.
• COMP : Outputs the compression level during
transmit.
• V : Outputs the drain terminal voltage of the
d
final amplifier MOSFETs.
• I : Outputs the drain current of the final am-
d
plifier MOSFETs.
• Approximately 2.5 V at 50% (default) setting for full-scale
indication. (4.7 kΩ impedance)
12-8
maximum: default)
50 %
