SDM-9000 Satellite Modem

4.2.5.4 Utility System

TIME/DATE
REMOTE/BAUD RATE/PARITY
REMOTE ADDRESS
OPERATION MODE
Rev.4
Displays current time and date.
To set the modem time and/or date, press [ENTER].
← →
Press [ ] or [ ] to position the flashing cursor over the
parameter to be changed. Press [
parameter to the desired value. Once the parameters are
displayed as desired, press [ENTER] to execute the
change.
The current parity and baud rate of the modem are
displayed. The parity can be set to:
• Even
• Odd
• None
The baud rate can be set from 110 to 19200 bit/s.
To set the modem baud rate and/or parity, press
← →
[ENTER]. Press [ ] or [ ] to position the flashing cursor
over the parameter to be changed. Press [
change the parameter to the desired value. Once the
parameters are displayed as desired, press [ENTER] to
execute the changes.
The current modem address is displayed (1 to 255).
To set the remote address, press [ENTER]. Press [
↓
[ ] to change the parameter to the desired value. Press
[ENTER] to execute the change.
Operation mode. Programs the modem operation for the
following operation:
• Duplex
• TX-only
• RX-only
On entry, the flashing cursor is displayed. Press [
→
[ ] to select TX only, RX-only, or Duplex. Press [ENTER]
to execute the change.
Note: When TX-only or RX-only is selected, the
appropriate faults are masked from the Faults and Stored
Faults menu.
Operation
↑ ↓
] or [ ] to change the
↑ ↓
] or [ ] to
↑
] or
←
] or
4–45
