Compatibility; Installation; Unpacking Instructions - Comtech EF Data SDM-9000 Installation And Operation Manual

Configuration

3.5.1 Compatibility

For proper modem operation, the installed interface, modulator, and demodulator must
be compatible with the installed filters. Refer to the following table for baseband
interface data rates.
Interface Type
G.703
ECL/PECL
MIL-STD-188

3.5.2 Installation

Installation instructions for the field-installed Nyquist filters (AS/4124) include:
•
•
•

3.5.2.1 Unpacking Instructions

CAUTION
1. Remove the Nyquist filter PCB and mounting hardware from the cardboard
2. Check packing list to ensure the shipment is complete.
3. Inspect the Nyquist filter PCB for any shipping damage. Ensure all ICs are
3–10
8.448 Mbit/s
32.064 Mbit/s
34.368 Mbit/s
44.736 Mbit/s
51.840 Mbit/s
6.0 to 52.0 Mbit/s, in 1 bit/s steps
6.0 to 13.0 Mbit/s, in 1 bit/s steps
Unpacking/initial inspection
Tools required
Installation procedure
This equipment contains parts and assemblies sensitive to damage by ESD.
Use ESD precautionary procedures when touching, removing, or inserting
PCBs.
caddypack and anti-static material.
seated properly.
Data Rates
SDM-9000 Satellite Modem
Rev. 4
