Operation

4.2.5.3 Utility Interface

TX OVERHEAD TYPE
RX OVERHEAD TYPE
TERRESTRIAL INTF
INTERFACE BUILD
INTERFACE OPTION
TX INTERFACE ESC
RX INTERFACE ESC
TX DATA PHASE
4–42
Select IDR or None for TX overhead type.
Note: The ESC option must be installed.
Select IDR or None for RX overhead type.
Note: The ESC option must be installed.
Displays the following interface type:
• G.703
• ECL
• PECL
• MIL-STD-188
Displays the interface module type (1, 2, or 3). This menu is a
status-only window reporting the following four types of modem
operation:
• Type 1 Base
• Type 2 Doppler Buffer
• Type 3 Doppler Buffer and ESC
This menu is a status-only window reporting the interface
options. The interface module options displayed are:
• Buffer
• ESC
• RS (EFD)
• RS (DVB)
• ESC-64K
This menu is a status-only window reporting the status of the
ESC interface. The TX options displayed are:
• 64K Data
• 2-32K Audio
This menu is a status-only window reporting the status of the
ESC interface. The RX options displayed are:
• 64K Data
• 2-32K Audio
Allows the user to invert TX data coming from the terrestrial
network.
On entry, press [
] or [
] to select Normal or Inverted. Press
[ENTER] to execute the change.
Note: This menu is only available for the ECL, PECL, or
MIL-STD-188 interface.
SDM-9000 Satellite Modem
Rev. 4
