2.4.8.3 ECL Interface (J8)

Ground
Send data input
Terrestrial timing input (TT)
SYNC TX frame input (TX SYNC)
Send timing output (ST)
Receive data output (RD)
Receive timing output (RT)
SYNC RX frame output (RX SYNC)
External clock input (EXC)
ADPCM 1 audio input
ADPCM 1 audio output
ADPCM 2 audio input
ADPCM 2 audio output
Backward alarm 1 output
Backward alarm 2 output
Backward alarm 3 output
Backward alarm 4 output
Backward alarm 1 input
Backward alarm 2 input
Backward alarm 3 input
Backward alarm 4 input
Modulator fault (TTL)
Demodulator fault (TTL)
Deferred maintenance Alarm
Demodulator fault relay
AGC output (receive input, if level)
2–12
Signal Function Name Pin #
GND 1, 2
TXD–A (ECL-) 37
TXD–B (ECL+) 38
TXO–A (ECL-) 4
TXO–B (ECL+) 5
SD–A (ECL-) 34
SD–B (ECL+) 18
TXC–A (ECL-) 21
TXC–B (ECL+) 22
RXD–A (ECL-) 39
RXD–B (ECL+) 40
RXC–A (ECL-) 23
RXC–B (ECL+) 24
RD–A (ECL-) 36
RD–B (ECL+) 20
EXC- (ECL-) 35
EXC+ (ECL+) 19
A1I–A 45
A1I–B 29
A1O–A 46
A1O–B 30
A2I–A 47
A2I–B 31
A2O–A 48
A2O–B 32
BWO1–C 8
(Note 1
BWO1–NC 25
BWO1–NO 41
BWO2–C 9
(Note 1
BWO2–NC 26
BWO2–NO 42
BWO3–C 10
(Note 1)
BWO3–NC 27
BWO3–NO 43
BWO4–C 11
(Note 1)
BWO4–NC 28
BWO4–NO 44
BWI1 12
(Note 2)
BWI2 13
(Note 2
BWI3 14
(Note 2)
BWI4 15
(Note 2)
MF 49
(Note 3)
DF 33
(Note 3
DMA 17
(Note 3)
DF–C 16
(Note 4
DF–NO 50
AGC–OUT 3
