Remote Control Operation
Modulator
Command:
Status
Response:
Demodulato
Command:
r Status
Response:
Interface
Command:
Transmit
Response:
Side Status
Interface
Command:
Receive
Response:
Side Status
B–14
<add/MS_'cr'
>add/MS_'cr'
RF_xxx'cr'
MOD_xxx'cr'
SYN_xxx'cr'
DCA_xxx'cr'
DCS_xxx'cr'
ICH_xxx'cr'
QCH_xxx'cr'
AGC_xxx'cr'
SCT_xxx'cr'
EXT_xxx'cr'
PROG_xxx'cr'
CONF_xxx'cr'
SFLT_xx'cr''lf']
<add/DS_'cr'
>add/DS_'cr'
MOD_xxx'cr'
CD_xxx'cr'
SYN_xxx'cr'
RCS_xxx'cr'
ICH_xxx'cr'
QCH_xxx'cr'
DSCR_xxx'cr'
BERT_xxx'cr'
PROG_xxx'cr'
CONF_xxx'cr'
SFLT_xx'cr''lf']
<add/ITXS_'cr'
>add/ITXS_'cr'
TXD_xxx'cr'
PLL_xxx'cr'
CLK_xxx'cr'
PROG_xxx'cr'
CONF_xxx'cr'
SFLT_xx'cr''lf']
<add/IRXS_'cr'
>add/IRXS_'cr'
UNFL_xxx'cr'
OVFL_xxx'cr'
RXD_xxx'cr'
FBER_xxx'cr'
CLK_xxx'cr'
PLL_xxx'cr'
DMUX_xxx'cr'
2047_xxx'cr'
BUFF_xxx'cr'
PROG_xxx'cr'
CONF_xxx'cr'
SFLT_xx'cr''lf']
RF Output (ON/OFF) Actual Status, Not Config.
Module
IF Synthesizer
Data Clock Activity
Data Clock Synthesizer
I Channel
Q Channel
AGC Level
Internal SCT Synthesizer
External Reference Activity
Programming
Configuration
Number of Stored Faults Logged (0 to 10)
Demod Module
Carrier Detect
IF Synthesizer Lock
Receive Clock Synthesizer
I Channel
Q Channel
Descrambler
BER Threshold
Programming
Configuration
Number of Stored Faults Logged (0 to 10)
Transmit Data/AIS
Transmit Synthesizer PLL Lock
Selected Transmit Clock Activity
Programming
Configuration
Number of Stored Faults Logged (0 to 10)
Buffer Underflow
Buffer Overflow
Receive Data Loss/AIS
Frame BER
Selected Buffer Clock Activity
Buffer Clock PLL Lock
Demux Lock
2047 Pattern Lock Detect
Buffer Full
Programming
Configuration
Number of Stored Faults Logged (0 to 10)
SDM-9000 Satellite Modem
Rev. 4
