Operation
TEST MODE STATUS
LAMP TEST ??
MASTER RESET
M&C MODULE FW
DISPLAY CONTRAST
4–46
Test mode status indicator. The following modem test
points are listed in this window and will display a "+"
when a test mode is active:
• RF Output
• Reed-Solomon
• RX 2047 Pattern
• TX 2047 Pattern
• Interface Loopback
• B-Band Loopback
• RF Loopback
• IF Loopback
• Carrier Mode
To view the test modes, press [ENTER]. Press [
to move through the list of test modes.
Lamp test function to test all the front panel indicators.
Press [ENTER] to turn on all of the front panel indicators
for three seconds.
Master reset function.
• HARD resets the switch to the defaults in ROM.
• SOFT resets the switch to stored configuration.
CAUTION
Initiating a hard reset will result in the modem being
configured to the default settings in ROM. Initiating a
soft reset will reset the modem hardware, but will
save the current configuration settings.
Note: The following parameters do not revert to default
settings after a hard reset:
• Address
• Parity
• Baud Rate
• Ext AGC: Min Pwr
• Ext AGC: Max Pwr
• Display Contrast
Press [ENTER] to begin. Press [
HARD or SOFT. Press [ENTER], then press [→] five
times so the cursor is on YES. Press [ENTER] twice to
reset.
Displays the M&C module firmware version. The display
includes the month, day, and year.
Sets the contrast setting of the front panel menu from 0
to 100%.
Press [ENTER] to change the contrast of the front panel
↑
↓
display. Press [
] or [
] to increment or decrement the
number at the flashing cursor from
0 to 100. Press [ENTER] to execute the change.
SDM-9000 Satellite Modem
←
→
] or [
]
←
→
] or [
] to select
Rev. 4
