SDM-9000 Satellite Modem
Interface
Command:
Config.
Response:
Status
Modem
Command:
Faults
Response:
Status
(Summary)
Rev. 4
<add/ICS_'cr'
>add/ICS_'cr'
ERF_nnnnn.nnn'cr'
TCP_xxx'cr'
RCP_xxx'cr'
BBL_xxx'cr'
ILB_xxx'cr'
ILT_xxx'cr'
ICFT_xxxx'cr'
ICFR_xxxx'cr'
SE_xxx'cr'
DE_xxx'cr'
BC_xxx'cr'
IBS_nn'cr'
ITOT_xxxx'cr'
IROT_xxxx'cr'
ISP_xxx'cr'
IRE_xxx'cr'
TDF_xxxx'cr'
RDF_xxxx'cr'
ISCL_TX1_nnn'cr'
ISCL_TX2_nnn'cr'
ISCL_RX1_nnn'cr'
ISCL_RX2_nnn'cr'
TDP_xxxx'cr'
RDP_xxxx'cr'
BW_TX1_nnn'cr'
BW_TX2_nnn'cr'
BW_TX3_nnn'cr'
BW_TX4_nnn'cr'
BW_RX1_nnn'cr'
BW_RX2_nnn'cr'
BW_RX3_nnn'cr'
BW_RX4_nnn'cr'
SCRT_xxxxxxx'cr'
DSCT_xxxxxxx'cr'
IRFS_6312_ssss'cr'
IRFS_8448_ssss'cr'
IRFS_32064_ssss'cr'
IRFS_34368_ssss'cr'
IRFS_44736_ssss'cr'
IRFS_51840_ssss'cr''lf']
<add/MFS_'cr'
>add/MFS_'cr'
DMD_xxx'cr'
MOD_xxx'cr'
ITX_xxx'cr'
IRX_xxx'cr'
CEQ_xxx'cr'
BWAL_xxx'cr''lf']
External Reference Frequency
Transmit Clock Phase
Receive Clock Phase
Baseband Loopback
Interface Loopback
Interface Loop Timing
Interface Coding Format Transmit
Interface Coding Format Receive
Scrambler Enable
Descrambler Enable
Buffer Clock (Source)
Interface Buffer Size
Interface Transmit Overhead Type
Interface Receive Overhead Type
Interface Substitution Pattern (TX 2047)
Interface Read Error (RX 2047)
Transmit Data Fault
Receive Data Fault
Service Channel Level TX1
Service Channel Level TX2
Service Channel Level RX1
Service Channel Level RX2
Transmit Data Phase
Receive Data Phase
Backward Alarm Enable TX1
Backward Alarm Enable TX2
Backward Alarm Enable TX3
Backward Alarm Enable TX4
Backward Alarm Enable RX1
Backward Alarm Enable RX2
Backward Alarm Enable RX3
Backward Alarm Enable RX4
Scrambler Type
Descrambler Type
Interface Receive Frame Structure (6312)
Interface Receive Frame Structure (8448)
Interface Receive Frame Structure (32064)
Interface Receive Frame Structure (34368)
Interface Receive Frame Structure (44736)
Interface Receive Frame Structure (51840)
The Interface Configuration Status command causes a block
of data to be returned by the addressed modem. The block
reflects the current configuration of the interface. Additional
configuration status of new options and features will always be
appended to the end.
Demodulator
Modulator
Interface Transmit Side
Interface Receive Side
Common Equipment
Backward Alarms
Remote Control Operation
B–13
