Remote Control Operation

B.2 Message Structure

The ASCII character format used requires 11 bits/character:
•
•
•
•
Messages on the remote link fall into the categories of commands and responses.
Commands are messages which are transmitted to a satellite modem, while responses are
messages returned by a satellite modem in response to a command.
The general message structure is as follows:
•
•
•
•
B.2.1 Start Character
A single character precedes all messages transmitted on the remote link. This character
flags the start of a message. This character is:
•
•
B.2.2 Device Address
The device address is the address of the one satellite modem which is designated to receive
a transmitted command, or which is responding to a command.
Valid device addresses are 1 to 3 characters long, and in the range of 1 to 255. Address 0 is
reserved as a global address which simultaneously addresses all devices on a given
communications link. Devices do not acknowledge global commands.
Each satellite modem which is connected to a common remote communications link must
be assigned its own unique address. Addresses are software selectable at the modem, and
must be in the range of 1 to 255.
B–2
1 start bit
7 information bits
1 parity bit
2 stop bits

Start Character

Device Address

Command/Response
End of Message Character
"<"
for commands
">"
for responses
