SDM-9000 Satellite Modem
Modulator/
Command:
Coder
Response:
Config.
Program
Status
Demodulato
Command:
r Config.
Response:
Status
Rev. 4
<add/MCP_'cr'
>add/ MCP_'cr'
SMT_xxxxxx'cr'
ITOT_xxxx'cr'
MOM_xxxxxxx'cr'
MF_nnn.nnnn'cr'
MR_nnnnn_mmmmm.mmm'cr'
MPO_snn.n'cr'
MOP_snn.n'cr'
SE_xxx'cr'
DENC_xxx'cr'
TCP_xxx'cr'
BBL_xxx'cr'
ILB_xxx'cr'
ILT_xxx'cr'
ICFT_xxxx'cr'
ISP_xxx'cr'
TDF_xxxx'cr'
ISCL_TX1_nnn'cr'
ISCL_TX2_nnn'cr'
TDP_xxxx'cr'
MRC_xxx'cr'
MSR_xxx'cr'
RSEN_xxx'cr'
BW_TX1_nnn'cr'
BW_TX2_nnn'cr'
BW_TX3_nnn'cr'
BW_TX4_nnn'cr'
SCRT_xxxx'cr'
RF_xxx'cr''lf']
<add/DCS_'cr'
>add/DCS_'cr'
DF_nnn.nnnn'cr'
DR_nnnn_mmmm.mmm'cr'
ADRA_nnnn_mmmm.mmm'cr'
ADRB_nnnn_mmmm.mmm'cr'
ADRC_nnnn_mmmm.mmm'cr'
ADRD_nnnn_mmmm.mmm'cr'
DDEC_xxx'cr'
RFL_xxx'cr'
IFL_xxx'cr'
BERT_xxxx'cr'
DSR_xxx'cr'
RSDE_xxx'cr'
SWR_nnnnnn'cr''lf']
System Modem Type
Interface Transmit Overhead Type
Modem Operation Mode
Modulator Frequency
Modulator Rate
Modulator Power Offset
Modulator Output Power
Scrambler Enable (ON/OFF)
Differential Encoder (ON/OFF)
Transmit Clock Phase
Baseband Loopback
Interface Loopback
Interface Loop Timing
Interface Coding Format Transmit
Interface Substitution Pattern (TX 2047)
Transmit Data Fault
Service Channel Level TX1
Service Channel Level TX2
Transmit Data Phase
Modulator Reference Clock
Modulator Spectrum Rotation
Reed-Solomon Encoder (ON/OFF)
Backward Alarm Enable TX1
Backward Alarm Enable TX2
Backward Alarm Enable TX3
Backward Alarm Enable TX4
Scrambler Type
RF Output (ON/OFF)
This command is used by the EFData M:N protection switch to
collect information that is necessary to configure back-up
modems. Because this command (content and/or order) can
be changed at any time by EFData, it is advisable that other
commands ('MCS_' and 'ICS_', or 'BCS_') be used for M&C
systems.
Demodulator Frequency
Demodulator Rate
Preset 'A' Assignment
Preset 'B' Assignment
Preset 'C' Assignment
Preset 'D' Assignment
Differential Decoder
RF Loopback
IF Loopback
BER Threshold
Demodulator Spectrum Rotation
Reed-Solomon Decoder
Sweep Width Range
The Demodulator Configuration Status command causes a
block of data to be returned by the addressed modem. The
block of data reflects the current configuration of the demod.
Additional configuration status of new options and features will
always be appended to the end.
Remote Control Operation
B–11
