SDM-9000 Satellite Modem

B.5 Stored Faults

Information on stored faults is returned when requested. If no stored fault exists for a
given fault number, the words "NO Fault" will be returned instead of the normal
time/date status information.
The following symbols are commonly used to define the stored faults status commands:
•
•
•
•
•
•
•
Modulator Command:
Stored Response:
Faults
Demodulato Command:
r Stored Response:
Faults
Interface Command:
Transmit Response:
Side Stored
Faults
Rev. 4
# Fault number (0 to 9). "0" is the first fault stored.
hh Hours in 24-hr. format.
mm Minutes.
ss Seconds.
MM Month.
DD Day.
YY Year.
<add/MSF_#'cr'
>add/MSF_# hh:mm:ss MM/DD/YY'cr'
MOD_xxx'cr'
SYN_xxx'cr'
DCA_xxx'cr'
DCS_xxx'cr'
ICH_xxx'cr'
QCH_xxx'cr'
AGC_xxx'cr'
SCT_xxx'cr'
EXT_xxx'cr'
PROG_xxx'cr'
CONF_xxx'cr''lf']
<add/DSF_#'cr'
>add/DSF_# hh:mm:ss MM/DD/YY'cr'
MOD_xxx'cr'
CD_xxx'cr'
SYN_xxx'cr'
RCS_xxx'cr'
ICH_xxx'cr'
QCH_xxx'cr'
DSCR_xxx'cr'
BERT_xxx'cr'
PROG_xxx'cr'
CONF_xxx'cr''lf']
<add/ITSF_#'cr'
>add/ITSF_# hh:mm:ss MM/DD/YY'cr'
TXD_xxx'cr'
PLL_xxx'cr'
CLK_xxx'cr'
PROG_xxx'cr'
CONF_xxx'cr''lf']
Module
IF Synthesizer
Data Clock Activity
Data Clock Synthesizer
I Channel
Q Channel
AGC Level
Internal SCT Synthesizer
External Reference Activity
Programming
Configuration
Demod Module
Carrier Detect
IF Synthesizer Lock
Receive Clock Synthesizer
I Channel
Q Channel
Descrambler
BER Threshold
Programming
Configuration
Transmit Data/AIS
Transmit Synthesizer PLL Lock
Selected Transmit Clock Activity
Programming
Configuration
Remote Control Operation
B–19
