SDM-9000 Satellite Modem
EXT AGC: MAX PWR
EXT AGC: MIN PWR
Rev.4
Sets the AGC voltage for an RX signal level of -25 dBm.
The voltage range is 0.0 to 10.0V, in 0.5V steps.
On entry, the current external AGC voltage level is
↑
↓
displayed. Press [
] or [
] to change the AGC voltage
level in 0.5V steps. Press [ENTER] to execute the
change.
Note: For any RX signal level between -25 and -50 dBm,
the software will interpolate the required AGC voltage.
Sets the AGC voltage for an RX signal level of -50 dBm.
The voltage range is 0.0 to 10.0V, in 0.5V steps.
On entry, the current external AGC voltage level is
↑
↓
displayed. Press [
] or [
] to change the AGC voltage
level in 0.5V steps. Press [ENTER] to execute the
change.
Note: For any RX signal level between -25 and -50 dBm,
the software will interpolate the required AGC voltage.
Operation
4–47
