SDM-9000 Satellite Modem
Interface Command:
Receive Response:
Framing
Structure Status:
Response:

B.3.4 System

Time of Day Command:
Response:
Status:
Response:
Date Command:
Response:
Status:
Response:
Remote Command:
Response:
Clear Command:
Stored Response:
Faults
Modem Command:
Operation Response:
Mode
Status:
Response:

System

Command:
Modem Response:
Type
Status:
Response:
Save Command:
Modem Response:
Config.
Recall Command:
Modem Response:
Config.
Rev. 4
<add/IRFS_fffff_ssss'cr'
>add/IRFS_fffff_ssss'cr''lf']
<add/IRFS_fffff_ssss'cr'
>add/IRFS_fffff_ssss'cr''lf']
<add/TIME_hh:mmxx'cr'
>add/TIME_hh:mmxx'cr''lf']
<add/TIME_'cr'
>add/TIME_hh:mmxx'cr''lf']
<add/DATE_mm/dd/yy'cr'
>add/DATE_mm/dd/yy'cr''lf']
<add/DATE_'cr'
>add/DATE_mm/dd/yy'cr''lf']
<add/REM_'cr'
>add/REM_'cr''lf']
<add/CLSF_'cr'
>add/CLSF_'cr''lf']
<add/MOM_xxxxxxx'cr'
>add/MOM_xxxxxxx'cr''lf']
<add/MOM_'cr'
>add/MOM_xxxxxxx'cr''lf']
<add/SMT_xxxxxxxx'cr'
>add/SMT_xxxxxxxx'cr''lf']
<add/SMT_'cr'
>add/SMT_xxxxxxx'cr''lf']
<add/SMC_n'cr'
>add/SMC_n'cr''lf']
<add/RMC_n'cr'
>add/RMC_n'cr''lf']
Where:
fffff = 6312, 8448, 32064, 34368, 44736, or 51840 (frame
type).
ssss = NONE, G704, G742, G743, G745, G747, G751,
G752, G753, or STS1 (framing).
Notes:
1. Valid 6312 frame structures are NONE, G704, G743,
and G747.
2. Valid 8448 frame structures are NONE, G704, G742,
and G745.
3. Valid 32064 frame structures are NONE and G752.
4. Valid 34368 frame structures are NONE, G751, and
G753.
5. Valid 44736 frame structures are NONE and G752.
6. Valid 51840 frame structures are NONE and STS1.
Where:
hh = 1 to 12 (hours).
mm = 00 to 59 (minutes).
xx = AM or PM.
Where:
mm = 1 to 12 (month).
dd = 1 to 31 (day).
yy = 00 to 99 (year).
The Remote command configures the modem for remote
operation. The modem will respond to any status request at
any time. However, the modem must be in Remote Mode to
change configuration parameters.
This command is used to clear all stored faults logged by the
modem.
Where: xxxxxxx = TX_ONLY, RX_ONLY, or DUPLEX.
This command configures the modem for simplex or duplex
operation modes. When transmit-only mode is selected,
receive faults are inhibited. When receive-only mode is
selected, transmit faults are inhibited.
Where: x = INTELSAT, DBS, or N5500.
Where: n = 1, 2, 3, 4, or 5 (stored configuration number).
Where: n = 1, 2, 3, 4, or 5 (stored configuration number).
Remote Control Operation
