SDM-9000 Satellite Modem
SDM-9000 "TYPE"
VER: 6.1.1
RAW BER
2.4 E-3
CURRENT RAW BER
Low limit: based on performance.
High Limit: based on data/code rate.
NO DATA (if carrier not locked).
SWEEP FREQUENCY
CURRENT SWEEP
FREQUENCY
(-60,000 to +60,000 Hz).
Rev. 4
FUNCTION SELECT
MONITOR
CORRECTED BER
4.0 E-3
CURRENT CORRECTED BER
Low limit: based on performance.
High limit: 1.0 E-12.
NO DATA (if carrier not locked).
BUFFER FILL
CURRENT BUFFER FILL STATUS
(1 to 99%)
or
NO DATA (if carrier not locked).
Only available when buffer installed.
Key:
ACCESS TO
SUBMENU

Figure 4-8. Monitor Menu

EB/N0
CURRENT Eb/N0
Low limit: based on data rate.
High limit: 16.0 dB.
NO DATA (if carrier not locked).
CURRENT FRAME/2047 BER
Low limit: based on performance,
High limit: based on data/code rate,
or
NO DATA (if carrier not locked),
or
SAMPLING (if collecting data).
CONDITIONAL OR
Parameter Information
OPTION-DEPENDENT
Operation
RECEIVE SIGNAL
-45 dBm
CURRENT RECEIVE
LEVEL
(-25 to -50 dBm)
FRAME ERRORS
4–21
