Remote Control Operation
Demodulato
Command:
r Rate
Response:
Status
Receive
Command:
Signal Level
Response:
Status
Interface
Command:
Buffer Fill
Response:
Status
Current
Command:
Sweep
Response:
Value
B–18
<add/DR_'cr'
>add/DR_nnnn_mmmm.mmm'cr''lf']
<add/RSL_'cr'
>add/RSL_xsnndBm'cr''lf']
<add/IBFS_'cr'
>add/IBFS_nn%'cr''lf']
<add/CSV_'cr'
>add/CSV_snnnnn'cr'
CD_xxx'cr''lf']
SDM-9000 Satellite Modem
Where:
nnnnn = One of the following decoder rates:
1/2 (QPSK 1/2)
3/4 (QPSK 3/4)
7/8 (QPSK 7/8)
16Q34 (16QAM 3/4)
16Q78 (16QAM 7/8)
8P23 (8PSK 2/3)
8P56 (8PSK 5/6)
N/A (Not Assigned)
mmmmm.mmm = Data rate in kHz.
Where:
x = < or > (data modifier to indicate that the receive
signal level is less than or greater than the returned
value).
s = + or - (receive signal level sign, plus or minus).
nn = 0 to 99 (receive signal level magnitude).
Notes:
1. The 'x' (< or >) parameter is only returned if the
level has exceeded the computational resolution of
the system.
2. 'No Data' is returned if the level cannot be
calculated.
3. 'Sampling' is returned if not enough data is currently
available to calculate the level.
Where: nn = 1 to 99 (relative to buffer depth).
Where:
s = + or - (sweep offset from center).
nnnnn = 0 to 60000.
xxx = OK or FLT (decoder lock status OK or FAULT).
This command returns the current sweep value and the
decoder lock status.
Rev. 4
