Chapter 2. Installation; Unpacking - Comtech EF Data SDM-9000 Installation And Operation Manual

This chapter includes instructions for unpacking and installing the modem, a description
of the external connections, and backward alarm information.
CAUTION

2.1 Unpacking

The modem and manual are packaged in preformed, reusable cardboard cartons
containing foam spacing for maximum shipping protection. The circuit cards are packed
in separate cardboard caddypacks (also packaged within the cardboard carton).
CAUTION
To remove the modem:
1. Cut the tape at the top of the carton (indicated by OPEN THIS END).
2. Remove the cardboard/foam spacer covering the modem and caddypacks.
3. Remove the modem, caddypacks, manual, and power cord from carton.
4. Save the packing material for storage or reshipment purposes.
5. Inspect the equipment for any possible damage incurred during shipment.
6. Check the equipment against the packing list to ensure the shipment is complete.
7. Refer to Section 2.2 for further system installation instructions.
Rev. 4
This equipment contains parts and assemblies sensitive to damage by
Electrostatic Discharge (ESD). Use ESD precautionary procedures when
touching, removing, or inserting PCBs.
Do not use any cutting tool that will extend more than 1" into the container
and cause damage to the modem.
