Network Settings Page

Each time you turn on the printer, the 4400N prints a Network Settings page. Another way to print a Network
Settings page is:
1. Go to the URL Configuration Page, the URL is
http://<IP address>/configure.html.
2. Click on the Network Administration link. This displays the Network Administration Page.
3. Click Configure Status Page, then click Generate Now. (The Network Administration Page is described
beginning on page 75.)
The Network Settings page provides information about the network printer settings and network connections. You
should review this page immediately after NIC installation and any time you change the configuration to verify
that the procedure was done properly.
In the illustration at the right, important features are circled. The Unit Serial No. (which is also on the back of the
NIC), is used for printer identification in peer to peer and NetWare protocols. The Network Address is the
hardware address or MAC address. The Protocol Address is the IP address you assign the 4400N printer. You can
set a new AppleTalk Printer Name using the Apple Printer Utility.
The Network Settings Page
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Unit Serial No: 992048
Network Address: 00:40:af:79:19:80
Network Topology: Ethernet
Network Speed: 10 Megabits
Novell Network Information
Print Server Name: NEC_992048
Password Defined: No
Preferred Server Name not defined
Directory Services Context not defined
Frame Type: Novell 802.3
Peer-to-Peer Information
Frame Type: 802.03
Network ID: 32803
TCP/IP Network Information
Frame Type: Ethernet II
Subnet Mask: 255.255.255.0
DNS Address: 0.0.0.0
AppleTalk Network Information
Frame Type: 802.2 SNAP On 802.3
Preferred Appletalk Zone:*
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Novell Connection Information
Printer Name: NEC_992048_P
File Server: LABNW312
Queue: NEC_992048_Q
No Notify Defined
Peer-to-Peer Connection Information
Printer Name: NEC_992048
AppleTalk Connection Information
AppleTalk Printer Name: SuperScript 4400 4
TCP/IP Connection Information
Port Number: 10001
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
F
EATURES
Version: 05.20
Connector:RJ45
enabled
enabled
enabled
Protocol Address: 131.241.45.84
Default Gateway: 131.241.45.254
enabled
San Jose EtherNet
Priority: 1 Attached: Yes
