TCP/IP Setup

You can use the operator panel to enable and set up the TCP/IP networking parameters for the printer. This is
particularly useful for setting the network IP address so you can use it as the printer's URL in web-based printing.
Follow these steps.
1. Press the Online button of the Operator Panel.
2. Press the Menu button to enter menu mode.
3. Press the Next button until
4. Press the Next button until
5. Press the Next button until
6. Press the Next button until
7. Use the Operator Panel buttons to set values for each of the 12 digits in this manner.
First press Next to set the curser to the first digit.
For the first digit, press Select to increment to the correct value. Then press Next to move to the next digit and
press Select to increment to its correct value. Continue until all twelve digits are set. When the final digit is set,
press Next to confirm the Net Address you set and then press Select.
8. Press Menu to exit menu mode and press Online to bring the printer online.
, and
SUBNET MASK GATEWAY
To validate any changes to network settings, you must turn the printer off, and then on again.
U M
SING THE ENU
You can use the Operator Panel to set communications channels, print forms or pages, view usage reports, use
special features, or change printer settings. (However, in most cases, you will use your printer drivers to change
printer settings.) Follow these three basic steps to enter menu mode and navigate through the menu tree
1. Turn on the printer, if necessary.
2. Press Online to turn the indicator light off and take the printer offline. The display changes from
.
OFFLINE
3. Press Menu. The display changes to
4. You navigate through the menu tree by pressing the menu selection buttons on the operator panel.
• Press Next to go to the next item in a menu.
• Press Previous to go to the previous item in a menu.
• Press Select to go to the next menu level or to choose the displayed setting if you are at the lowest menu level.
• Press Item to move back to the previous menu level.
• Press Menu to exit menu mode. If you changed any network settings, you must restart the printer to validate
the new settings
• An Example of Using the Menu Tree
OFFLINE
CONTROL
appears on the display, and press the Select button.
COMMUNICATIONS
appears on the display, and press the Select button.
NETWORK
appears on the display, and press the Select button.
TCP/IP
appears on the display, and press the Select button.
NET ADDRESS
are set in the same way. If you select
T
REE
MENU CONTROL
appears on the display.
appears on the display.
, the TCP/IP protocol is enabled.
ENABLE
.
to
READY

Using the Menu Tree
