Operator Panel Buttons

Operator panel buttons have different functions depending on whether the printer is online, offline, or in menu
mode. The table below summarizes Operator Panel buttons. The operator panel menu tree and procedures for
changing printer settings are discussed beginning on xxx.
Button Mode
Online Offline Press to bring printer online.
Online Press to take printer offline.
Menu Button is not active.
Feed Offline In PCL emulation or Automatic Emulation Switching (AES) mode, pressing this button with the DATA
indicator light on allows data stored in the print buffer to be printed out. This button is not active in
PostScript emulation mode. [If a paper mismatch occurs, press this to print using the paper in the tray.
Online Button is not active.
Menu Button is not active.
Menu Offline Press to enter the menu mode. The menu item, Printer Menu, appears on the status display.
Online Button is not active.
Menu Press to exit menu mode.
Media Offline Press once to change media to Label (Thick stock) Green LED light turns on. Press again to return to
plain paper. When the printer detects overhead transparencies in the paper tray, the button is not active.
Online Button is not active.
Menu Button is not active.
Item Offline Button is not active.
Online Button is not active.
Menu Press to go back one menu level.
Previous Offline Button is not active.
Online Button is not active.
Menu Press to display previous item in a menu.
Next Offline Button is not active.
Online Button is not active.
Menu Press to display next item in a menu.
Select Offline Button is not active.
Online Button is not active.
Menu Enables changes made to settings in the menu tree.
26 SuperScript 4400 — Maintenance Guide
Function
