Replacing The Ozone Filter; Replacing The Toner Collector - NEC Super Script 4400 Maintenance Manual

R
EPLACING THE
Part number xxx
The Ozone filter needs to be replaced about every 12 months. A message on the Operator Panel will remind you of
this. Follow these instructions to change the Ozone Filter.
1. Slide open the Filter Cover located in back of the printer.
2. Take the used Ozone Filter from inside the Filter Cover and discard it.
3. Fit the new Ozone Filter inside the Filter Cover and slide it shut.
R
EPLACING THE
Part number 20-213
The Toner Collector is a replaceable plastic bottle that collects used toner. Follow these directions to change it:
1. Open the Front Cover of the printer.
2. Remove the used Toner Collector.
3. Note the label attached to the used Toner Collector. Remove this label and use it to seal shut the opening.
4. Discard the used Toner Collector.
5. Install the new Toner Collector.
114 SuperScript 4400 — Maintenance Guide
O F
ZONE ILTER
T C
ONER OLLECTOR
